型号 Type | 过滤面积(m2) Filtering Area | 叶片直径(mm) Leaf Diameter | 工作温度(℃) Working Temperature | 工作压力(MPa) Working Pressure | 外形尺寸(mm) Outline Dimension |
ZFPY-3NA | 3 | 400 | ≤150 | 0.4 | 600×2000 |
ZFPY-5NA | 5 | 600 | 800×2600 | ||
ZFPY-8NA | 8 | 600 | 800×2900 | ||
ZFPY-10NA | 10 | 850 | 1000×3800 | ||
ZFPY-12NA | 12 | 850 | 1000×4000 | ||
ZFPY-15NA | 15 | 850 | 1000×4500 | ||
ZFPY-20NA | 20 | 1000 | 1200×5500 | ||
ZFPY-25NA | 25 | 1000 | 1200×5800 | ||
ZFPY-30NA | 30 | 1000 | 1200×6500 | ||
ZFPY-35NA | 35 | 1200 | 1400×6800 | ||
ZFPY-40NA | 40 | 1200 | 1400×7500 | ||
ZFPY-45NA | 45 | 1200 | 1400×8200 | ||
ZFPY-50NA | 50 | 1220 | 1400×8900 | ||
ZFPY-60NA | 60 | 1200 | 1400×10000 |
高邮市铸锋机械制造有限公司
联系人：蔡先生
手 机：13805257618
电 话：0514-84683979,84681529
传 真：0514-84681569
地 址：高邮市经济开发区捷通路8号
